DIP28 with Pin Numbers

by AdamStanislav - uploaded on October 21, 2017, 7:47 pm

This shows the pinout of a 28-pin DIP. More description at the original (https://openclipart.org/detail/288864/28pin-dip).

Tags
analog controller digital DIP DIP28 dual Electronics electronics in-line lead micro microcontroller microelectronics package pin remix+288864
Safe for Work?
Yes
Download
SVG (Vector)
PNG (Bitmap) Small Medium Large
This clipart is a remix from:
  • 288864
    28-pin DIP
    by @AdamStanislav
